We took some of the components from the HD series and split them into smaller individual components for tight spaces. The VES ICEBOX can accept almost all upgrades that are available to the HD series. The VES ICEBOX is perfect for vans, RV’s, heavy duty construction equipment, or wherever you need additional cooling. Don’t have a big enough alternator charging system? Add some batteries and a battery charger to make the system isolated from the engine’s charge circuit. Available in 12/24 or 48 Volts DC.

FEATURES:

  • SMALL SPACE SAVING DESIGN

  • EVAPORATOR BRACKETS CAN BE LOCATED ON THE TOP OR BOTTOM OF THE ENCLOSURE FOR CEILING OR CABINET MOUNTING.

  • DEEP EVAPORATOR CONDENSATION TRAY IS PERFECT FOR OFF ROAD OR HEAVY EQUIPMENT

  • 360 DEGREE IP68 RATED 4” ROTATABLE BLOWER

  • COMPRESSOR CAN BE HIDDEN AWAY FROM VIEW

  • LOW POWER CONSUMPTION USING OUR “ALWAYS ACTIVE” EcoCruise VARIABLE COMPRESSOR TECHNOLOGY

  • LONG LASTING AMERICAN MADE 3 PHASE DC COMPRESSOR

  • AVAILABLE PARTS AND SERVICE FOR LONG TERM SUPPORT PAST THE WARRANTY PERIOD

Specifications:

OPERATING VOLTAGE    CURRENT CONSUMPTION   COOLING CAPACITY

12L- 10-15 VDC               12L- 38-55 AMPS*               12L- 10K BTU

24L- 20-31 VDC               24L- 25-33 AMPS*                 24L- 11K BTU

48L- 40-62 VDC               48L-  8-16  AMPS*                 48L- 12K BTU



*Current ratings are nominal. Current ratings can fluctuate depending on accessories and or operating conditions. Maximum BTU ratings shown. BTU ratings vary depending on voltage, installation, condenser options and refrigerant charge.

All specifications and features are subject to change without notice.
